2004 Custom Super Ice

This is a 580' Cruise Ship built in Finland in 2004. It is DNV-GL Class Super Ice 1A. There

are 734 Guest Cabins with 1,468 lower berths and up to 1,800 passengers. The ship has

full amenities. It has lovely modern styling. It is an "Eco Clean" design. Ship has current

certificates. This is a unique modern ship that can be used in all waters including for polar

cruising due to her rare Super Ice Class status. It has an glass enclosed pool for all

weather swimming.

Year Built: 2004

Yard Built: Aker Yard, Finland

Class: DNV+1A1, Passenger Ship Ice 1A, Finnish Ice Class 1A Super

COMF-V(1), Clean design, RP, EO, PMS, Tmon, NAUTAW

(without visibility aft)

PRINCIPAL DIMENSIONS

Gross Tons: 34,924 mt

Net Tons: 18,839 mt

DWT: 3,320 mt

LOA: 177.0 mt

LPP: 154.8 m

Beam: 28,0 m

Draft: 6.5 m

MACHINERY

Speed: 21 knots

Main Engines: 4 x Wärtsilä 6L46B 5,850 kW/500 rpm

Fuel Cons.: 178.5 g/kWh +/- 3%

Propulsion: Reduction Gears and elastic coupling, Propellers, hub (rst)

Pressure pulses < 1,5 kPa, 4 spare blades

Aux. Engines: 4 x Wärtsilä 6L32 2,760 kW/750 rpm

Fuel Cons.: 180 g/kWh +/- 5%

Generators: 4 x 3,312kVA/0.8 690V/50 Hz

Emerg. Gen: 1 x 700 kVA 7 1500 rpm 690V/50 Hz

Boilers: 2 x 6,000 kg/h at 7 bar, 2 x 1,000 kg/h exhaust boiler (ME) 4 x

800 kg/h exhaust boiler (AE)

Separators: 3 x HFO, 4 LO (HM) / 2 LO (AE)

Evaporator: 1 x 35 cbm /24h Space reserved for 2 x 150 cbm/24h osmosis

plants

Propellers: 4-bladed

Bow Thrusters: 2 x 1500 kW/1480 rpm

Stern Thruster: 1 x 1000 kW / 1480 rpm

Fin Stabilizers: Type Blohm + Voss

Bilge Wtr. Sep.:1-5 ppm. Type Marinfloc Distr. Voltage 690V/50Hz 3-

phase Integrated Automat. 3500 I/O points. Type

Valmarine System (IAS)

Tanks: Fuel 1,226 m3, Diesel 189 m3, Fresh water 1,300 m3, Ballast

water 1063 m3

Trim Tanks: 839 m3 Stabilizers B+W S500 simplex compact

NAUTICAL EQUIPMENT

Radar: 2 x Radar SAM

Radar Pilot: 1000 S-band Radar SAM

Radar Pilot: 1000 x-band’

Gyro Compass: Sperry Marine Navigat X

Gyro Compass Sperry Marine Nav. 2100

Autopilot: 2 x Autopilot Atlas 9401

Mag. Compass: Jupiter Speedlog: X 1

Echo Sounder: SAM 9205

GDPS: 2 x ECDIS:

Atlas Chartpilot: x 2 VDR:

AIS: x 1

Anemometer: x 1

Radio Station

MF/HF DSC GMDSS Area

A1 Atlas Debeg 3105 VHF DSC Sailor RT5022 x2

VHF Atlas Debeg 6301 CU x2

VHF Icom IC-GM 1600 E GMDSS x2

VHF Sailor SP 3540 x3 VHF AM Jotron Tron Air x2 VHF Jotron Tron VHF x2

Navtex Debeg 2900 Sart Debeg 5900 x 2

EPIRB Portable: Kannad Manual 406Mhz

EPIRB Float free: Kannad Auto GPS

PASSENGER FACILITIES

Passengers: 1,800

Passenger Cabins: 2 persons x 404

Passenger Cabins: deluxe x 34

Passenger Cabins: 4 persons x 287

Passenger Cabins: suites x 9

Crew Cabins: x 181

ENTERTAINMENT & AMENITIES

Entrance Arcade

Supermarket

Arcade

Casino

Buffet Restaurant

A la carte Restaurant

Cafeteria

Children’s Area

Smoking Lounge

Dance Bar

Bistro

8 Bars

Spa/Sauna

Meeting Rooms

Lounge

Disco

Pool

Jacuzzis

Helicopter Landing Pad

Specifications

Condition: Laid Up

Vessel type: Cruise Ship

Builder: Aker

Model: Ice Class

Constructed: 2004

Registry: Swedish

Class Society: DNV

Class Notation: Ice Class Super 1A

Guests: 1

Berths: 1900

Cabins: 734

No. of engines: 4

Engine model: Wartsila 6L32

Engine power: 14,4740

Length over all: 580'

Length at waterline: 507' 10"

Beam: 91' 10"

Maximum draft: 21' 4"

Hull material: Steel

Hull type: Displacement

Keel type: Full Keel
